Co2 Laser Marking Machine

CO2-laser-marking-machine-3
CO2-laser-marking-machine-1
CO2-laser-marking-machine-2

We Provide Affordable co2 Laser Marking Machines

CO2 laser marking machine employs CO2 laser, with Co2 gas as the working substance, with higher power and electro-optical conversion efficiency. The machine is equipped with a high-speed scanning oscillator and beam expansion focusing system, resulting in high precision and fast marking. Currently, CO2 laser marking machines are primarily used in engraving non-metal and some metal materials.
Co2 laser marking machines are widely used for making permanent marks on the surface of non-metallic and organic materials. These machines employ CO2 gas in a sealed tube as a laser source to mark on materials such as wood, glass, and acrylic. This laser system is commonly used for product identification, serial marking, date stamping, and other purposes. We provide an outstanding range of fly laser marking machines in India, backed by a cutting-edge infrastructure unit and a staff of highly experienced and qualified employees.
Call Now: +91-9646458212

Micro provide the best service for sustainable progress

Buy High-Quality Co2 Laser Marking Machines at Market-Leading Prices!

As one of the top Co2 laser marking machine manufacturers in India, we guarantee to provide you with the most cost-effective solution for your business. Traceability is important in the manufacturing industry, ensuring that all items are tracked along the supply chain, from manufacture through distribution to the final customer.
Micro Industrial Solutions creates revolutionary and efficient CO2 laser marking equipment that establishes quality and durability standards. CO2 laser marking equipment is crucial in this procedure. They print unique and permanent marks on items such as serial numbers, bar codes, and QR codes, which manufacturers can use to gather vital track and trace data. We design our permanent marking solutions using high-quality materials that will last a long period. Our co2 laser marking machines are cost-effective tools for product identification and traceability. These machines can mark at high speeds while preserving mark quality, allowing for non-contrast marking in plastics and ink removal for date coding. If you need a high-quality marking machine, get it from one of the leading Co2 laser marking machine suppliers in India.

Co2 Laser Marking Machine Details

  • High optical energy conversion rate, which is one of the common features of all laser marking machines
  • The closed-tube CO2 laser marking machine has a high pulse frequency and can provide continuous output power.
  • Hundreds of spectral lines of laser output can be in the area of 10 microns.
  • High standard precision can be achieved -10 microns exact range output.
  • The wavelength is ideal, the transmission rate is high, the beam quality is excellent, the line width is thin, and the work is consistent.
  • Good directionality and good controllability.
  • Monochromatic frequency stability.
  • Low gas density and output density.

Technical Details

Contact Us
Type DAVI Metal tube
Power 30W/50W
Laser Source DAVI
Working Frequency 0-25 khz
Laser Wavelength 10.6um
Optional Marking Area 110mm*110mm/150mm*150mm/200mm*200mm
Marking Speed 7000mm/s
Minimum Character 0.15mm
Life-span of Fiber Laser Module 20, 000hours
Beam Quality M2 <1.5
Focus Spot Diameter <0.01mm
Output Power of Laser 10%~100% continuously to be adjusted
System Operation Environment Window7/8/10
Cooling Mode Air cooling
Temperature of Operation Environment 15℃~35℃
Power Input 220V / 50HZ / single phase or 110V / 60HZ / single phase
Power Requirement <900W
Communication Interface USB
Package Dimension 850*500*820mm
Gross weight 85KG
Optional (Not free of charge) Rotary Device, Moving Table, other customized Automation
